ATOM RS-232 is a TTL-RS232 level-converter designed for use with the M5Atomic module. RS232 is a full-duplex communication protocol standard, which defines the electrical characteristics of the serial communication system. It is a widely used communication protocol in the field of industrial control. MAX232 chip is integrated in the module, which supports bidirectional conversion between TTL level and RS232 level. A DC/DC voltage regulator chip is integrated in the ATOM RS-232, which can directly convert the 12V voltage of the RS232 hub to 5V to supply power for ATOM.
Product Features
- Compatible ATOM Matrix/ATOM Lite
- Built-in DC/DC
- Full-duplex communication
Include
- 1x ATOM RS-232
- 1x ATOM Lite
- 1x Hex Key
- 1x M2*8mm Hexagon socket cup head machine screw
- 1x 18cm TYPE-C Cable
Applications
- RS232 Communication
- Industrial control node
Specification
| Specification | Parameter |
|---|---|
| External port | VH-3.96 4P |
| level-conversion IC | MAX232 |
| DC-DC | A0Z1282CI |
| Net weight | 26g |
| Gross weight | 36g |
| Product Size | 24*48*18mm |
| Package Size | 54*54*20mm |
| Case Material | Plastic( PC ) |
