Description

Joystick HAT is one of the HAT module that is specifically designed for M5StickC. We have used a STM32F030F4 microprocessor inside to implement I2C communication with M5StickC.This mini-volume joystick module supports full angular movement and center press, and outputs angular data as well as button digital signals.With the 'HAT' unified plug-in design it can provide reliable connection, in the most streamlined way. which allowes to get more HMI experience.

Product Features

• STM32F030F4 inside
• communication protocol: I2C (address: 0x38)
• support omni-directional movement/button press

Include

• 1x Joystick HAT

Applications

• Game Handle
• Wireless Joystick Device

Specification
