HOME > STORE > [EOL] M5StickC ENV Hat (DHT12, BMP280, BMM150)
[EOL] M5StickC ENV Hat (DHT12, BMP280, BMM150)

SKU:U053

$5.95

EOL

Shipping calculated at checkout.
Description

Description

ENV HAT It is able to detect the temperature, humidity, air pressure and magnetic field. This product relates via I2C protocol which allows you to obtain 4 types of environment data thru just 2pins, together with the tiny body, makes it a powerful application for envitonment data collecting.

This product is EOL now, we've released the updated version M5StickC ENV HAT II.R (SHT30, BMP280) which is fully compatible with this product.

Product Features

  • temperature:

    • Range: -20 ~ 60 ℃

  • Humidity:

    • Range: 20 ~ 95 %RH

  • Air pressure:

    • Range: 300 ~ 1100hPa

  • Typical Magnetic Field：

    • ±1300μT（x，y-axis），±2500μT（z-axis）
    • magnetic field resolution: 0.3μT

Include

  • 1x ENV Hat

Applications

  • Weather Station
  • Compass

Specification

Resources Parameter
Communication protocol I2C：DHT12(0x5C),BMM150(0x10)
Net weight 4g
Gross weight 8g
Product Size 24*20*14mm
Package Size 36*38*18mm
Document

Contents

Customer Reviews

Based on 21 reviews
95%
(20)
5%
(1)
0%
(0)
0%
(0)
0%
(0)
O
Olaf Werner
one of the best HAT

The first ENV-Hat I ordered with the stick-C hat.
It was a fun-Project to build a weather-station and to learn to Use MQTT.
I made this a project for ma programming class.

d
dclaar
This little stick is so much fun!

The M5StickC is a lot of fun, and it is relatively easy to use. I am only giving 4 stars because some of the documentation is hard to decipher, and because the ENV hat is about 5 degrees C off.

UI flow is really approachable, and fun for a while--you can make things happen fast--but as a programmer, all that mouse clicking just got in the way of what I wanted to do.

Micropython was cool, and worked pretty well, but if you want to be able to use and adapt other people's libraries, learn from examples, Arduino is really the only way to go.

I'm still trying to wrap my head around the accelerometer & gyro maths and 3D, though!

B
Bob Reed
M5StickC Env Hat

Worked first time, is working great now...so far very reliable

m
michio honda

M5StickC ENV Hat (DHT12, BMP280, BMM150)

G
Geo
Best for prototyping and for IOT project

Nice device, work and look as expected
