ESP32 GRAY Development Kit with 9-Axis Sensor

SKU:K002

Regular price $44.90

EOL

Shipping calculated at checkout.

Description

M5Stack GRAY Kit is one of the M5Stack development kit series, which is a upgrade from the Basic kits. In comparison, Gray kit provides an extra IMU sensor, BMM150 + MPU6886. Gray kit is a nice choice for users who just get started or in progress.

With a IMU posture sensor, there are a lot of situations which u can apply this kit to: detecting acceleration, angulation, and trajectory. You can make relative products like sports data collector, 3D remote gesture controller and more base on the above functions.

GRAY is M5 Core device. Its modular, stackable, scalable, and portable device is powered with an ESP-32 core, which makes it open source, low cost, full-function, and easy for developers to handle new product development on all stages include circuit design, PCB design, software, mold design and production.

If you want to explore the fastest way of IoT prototyping, M5Stack development board is the perfect solution. Not like others, M5Stack development board is highly efficient, covered with industrial grade case and ESP32-based development board. It integrates with Wi-Fi & Bluetooth modules and contains a dual-core and 16MB of SPI Flash . Together with 30+ M5Stack stackable modules , 40+ extendable units and different levels of program language, you can create and verify your IoT product in a very short time.

Supportive development platforms and programming languages: Arduino, Blockly language with UIFlow , Micropython. Regardless of what level programming skill you have, M5Stack would guide you in every step of the way to realize your idea as well as to the final productlization.

If you ever played with ESP8266, you would realize that ESP32 is a perfect upgrade out of ESP8266. In comparison, ESP32 has more GPIOs, more analog inputs and two analog outputs, multiple extra peripherals( like a spare UART ). Official developing platform ESP-IDF has transplanted with FreeRTOS. With dual-core and real time OS you can get more organized code and much high speed processor.

Power on/off:
Power on: click the red power button on the left
Power off: Quickly double-click the red power button on the left
Note: By default, when USB is powered, it cannot be shut down**

Product Features

  • ESP32-based
  • Built-in Speaker, Buttons, LCD
  • TF card slot (Up to 16GB support)
  • Battery Socket & Lipo Battery
  • Extendable Pins & Holes
  • M-Bus Socket & Pins
  • Development Platform UIFlow , MicroPython , Arduino

Include

  • 1x Gray
  • 10x Femal-male Dupont
  • 1x Type-C USB(20cm)
  • 1x User Manual
  • 1x Sticker

Applications

  • Internet of things terminal controller
  • Stem education product
  • DIY creation

Specification

Resources Parameter
ESP32 240MHz dual core, 600 DMIPS, 520KB SRAM, Wi-Fi, dual mode Bluetooth
Flash Memory 16MB (old: 4MB)
Power Input 5V @ 500mA
Port TypeC x 1, GROVE(I2C+I/0+UART) x 1
IPS Screen 2 inch, 320x240 Colorful TFT LCD, ILI9342C, max brightness 853nit
Speaker 1W-0928
Button Custom button x 3
Core Bottom Port PIN (G1,G2,G3,G16, G17, G18, G19, G21, G22, G23, G25, G26, G35, G36)
MEMS BMM150 + MPU6886
Battery 110mAh @ 3.7V
Antenna 2.4G 3D Antenna
Operating Temperature 0°C to 60°C
Net weight 49.2g
Gross weight 93g
Product Size 54 x 54 x 18.9 mm
Package Size 95 x 65 x 25mm
Case Material Plastic ( PC )
