ATOM HUB DIY Proto Board Kit

SKU:K039

Regular price $7.95

10+ In Stock

Shipping calculated at checkout.
PRODUCT DETAILS

Description

ATOM HUB PROTO is a DIY expansion board kit designed specifically for the ATOM series. It allows users to build hardware circuits or connect external devices according to their specific needs and requirements. With the aim of providing versatile connectivity options, ATOM HUB PROTO offers a range of interfaces, including the VH3.96 interface, DC5V power interface, and GROVE interface. Additionally, the board features various pre-cut openings on the casing for convenient wiring. The back of the board is designed with multiple mounting holes, supporting traditional hanging holes, screw fixation holes, and compatibility with slide rail fixtures.

The board includes a built-in Proto circuit board with a main circuit space layout of 45x35x20mm. With ATOM HUB PROTO, you have the freedom to unleash your creativity and create your own hardware devices. For example, you can integrate a battery with a charging and discharging circuit, or incorporate a miniature air pump with an air pressure sensor to create a blood pressure monitor. You can even integrate a GPS module with an NB-IoT module to develop a location tracking system. The possibilities are endless, and the functionality is entirely up to your imagination and requirements.

Product Features

  • Compatible with ATOM Matrix/ATOM Lite
  • Compact design
  • Industrial applications
  • Multiple interface output
  • Multiple mounting holes
  • Creative DIY

Includes

  • 1x Proto board(include GROVE port)
  • 1x 3.96*4P Plug & Plug Base
  • 6x 3.96*3P Plug & Plug Base
  • 1x ATOM HUB PROTO Face shell
  • 1x DC 5V Power outlet
  • 4x Dust Plug
  • 1x DIN Rail
  • 2x Plastic
  • 4x Magnet double-side tape
  • 4x Rubberpad
  • 4x Magnet
  • 4x M2*6mm Hexagon self tapping screw
  • 1x M2*20mm Hexagon socket cup head machine screw
  • 2x M4*10mm Hexagon countersunk screw
  • 1x M2 Hex Key
  • 1x M4 Hex Key

Applications

  • Atom expansion board
  • Industrial controller node
  • Peripheral connection
  • DIY hardware

Specification

Specification Parameter
External port 1x VH-3.96 4P 6x VH-3.96 3P 1x DC5V Input 1x GROVE
Net weight 93g
Gross weight 105g
Product Size 72*40*30mm
Package Size 104 x 77 x 35mm
Case material Plastic ( PC )
